Din 1.4441 Grade Stainless Steel Round Bar SS 316LVM 5-60mm H9 Bright Finish

Name: Din 14441 Grade Stainless Steel Round Bar SS 316LVM 560mm H9 Bright Finish
Brand: MITTEL TISCO BAO STEEL
Price: 3.5 USD

Quality Din 1.4441 Grade Stainless Steel Round Bar SS 316LVM 5-60mm H9 Bright Finish wholesale

Brand Name : MITTEL TISCO BAO STEEL

Model Number : 316LV 1.4441

Certification : SGS ISO MTC

Place of Origin : China

MOQ : 300KGS

Price : 3.5 USD/KG

Payment Terms : L/C, D/A, T/T, Western Union, MoneyGram

Supply Ability : 50000KGS

Delivery Time : 7 Days

Packaging Details : Wooden Box

Type : Round

Application : Construction,decoration,Industry,Mechineal,shipbuilding

Standard : ASTM,AISI

Grade : 300 Series

Shape : Round

Dimensions : 5.5mm-500mm

Surface : bright,Polished

Product name : SS 201 304 316 410 420 2205 316L 310S Stainless Steel Round / flat Bar

Technique : Cold Rolled Hot Rolled

Packing : Standard Seaworthy Package

Price term : CIF CFR FOB Ex-Work

Contact Now

SS 316LVM / Din 1.4441 Grade Stainless Steel Round Bar (5-60mm) Tolerance - H9 Bright Finish

316LVM / 1.4441

Mittel steel with improved corrosion resistance compared to AISI 316L.

316LVM stainless steel or 1.4441 stainless steel (316L grade which confirms ISO 5832-1 norm) is a medical implant grade. This grade is written as 1.4441 or X2CrNiMo18-15-3 according to EN norm and it is written as UNS S31673 according to UNS norm. 316Lvm stainless steel is usually used inside the body parts. 316LVM stainless is bio-compatible stainless steel grade and 1.4441 grade can stay in side body for a very long time. 316LVM is also antimagnetic so this antimagnetic structure is very important for MRI machines. MRI machines works with extream magnetic fields and if any kind of material inside body is magnetic, then the machine can pull that magnetic part and this can cause injuries. 316LVM stainless steel is ready in Birçelik warehouse stocks and we only sell European Origin 1.4441 materials. 1.4441 stainless usually used in body part, prosthesis parts and dental parts.

Main fields of application of 1.4441

Osteosyntheses; bone screws, bone plates, marrow-nails. Also suitable for watch industry.

Chemical composition of 1.4441

C	≤ 0,030	Cr	17,0 - 19,0
Si	≤ 1,00	Mo	2,5 - 3,2
Mn	≤ 2,0	Ni	13,0 - 15,5
P	≤ 0,025	N	≤ 0,10
S	≤ 0,010	Fe	rest`

Mechanical properties of 1.4441

annealed	specification values (bars)
tensile strength Rm	490 - 690 MPa
elongation A	≥ 40%

cold worked	specification values (bars)
tensile strength Rm	860 - 1100 MPa (higher values upon demand)
elongation A	≥ 12%

Sheets of 1.4441

dimensions	kg/m2	tolerances
3,2	0,226	+0 / - 0.1 mm
4,5	1.013	+0 / - 0.1 mm

Bars of 1.4441

dimensions	kg/m	tolerances
6,0	0,22	h8
8,0	0,40	h8
12,7	1.01	h8

Further bars and profiles in different executions available upon request.

Delivery program

Various sizes and tolerances available upon request.

Services provided by our internal service center for 1.4441

We can provide various services directly in our service center. You save time, cost (internal or external) and don't need to find solutions for scrap management or handling of heavy plates and long bars.

Services suitable for sheets, plates, coils	Services suitable for round bars
laser and waterjet cutting	sawing of bars
shearing of sheets and plates	bar marking
coil slitting	turning machine
